Product features and component characteristics are one and two levels

Low Pressure Screw Air Compressor - Dual Stage: 4~6 Product Features

1. Applicable pressure in 4-6bar working conditions.

2. It adopts the characteristics of self-developed double-stage main engine, large rotor, low rotation, large outlet, low pressure ratio, low noise, high efficiency and other characteristics.

3. Separation of hot and cold zones, using the design concept of separation of hot and cold zones, electronically controlled independent inlet and outlet air duct system, independent air inlet system, and independent inlet and outlet air duct system for heat dissipation.

4. Automatic control, independent research and development, higher adaptability. The operation display system in Chinese/English is simple and intuitive to operate.

5. The design of the super large cooling system is increased by 30%, and the design margin is centrifugal fan, which has the characteristics of large wind pressure and low voice.

6. It adopts the design of super-large oil and gas separation, with quadruple separation such as centrifugation, diffusion, gravity and filtration. Imported polymer filter material, the filtration efficiency reaches 99.99%.

7. 45°C high-temperature protection design ensures normal operation at high temperatures.

Each unit achieves Class 1 energy efficiency, saving 15% more energy than
Class 2 units and 30% more than Class 3 units.

Reliable and Low-Noise

· Innovative air compressor layout design with optimized structure and
standardized assembly processes ensures precision at every stage. Full rigid
pipe connections enhance overall durability. The integrated vibration damping
and noise reduction system reduces noise by 30%, delivering quieter operation at
equivalent power levels.

High-Efficiency Coaxial Direct-Drive Integrated Structure

· The suspended coaxial direct-drive integrated structure minimizes
mechanical losses, extends motor lifespan, and boosts transmission efficiency.
The high-efficiency compressor features a large rotor, low-speed design, low
compression ratio, high volumetric efficiency, and a 10% improvement in
compression efficiency. The permanent magnet rare-earth motor achieves 5-7%
higher efficiency compared to asynchronous motors.

Product features and component characteristics are a single level

Low pressure screw air compressor - single stage product features

1. Applicable pressure under 2-4bar working conditions.

2. Adopt the characteristics of self-developed single-stage main engine, large rotor, low speed, large outlet, low pressure ratio, low noise, high efficiency and so on.

3. Adopt the design concept of hot and cold zone separation, electronically controlled independent inlet and outlet air duct system, independent air inlet system, and heat dissipation independent inlet and outlet air duct system.

4. Automatic control, independent research and development, higher adaptability. The operation display system in Chinese/English is simple and intuitive to operate.

5. It adopts a super-large oil and gas separation design, with quadruple separation such as centrifugation, diffusion, gravity, and filtration. Imported polymer filter material, the filtration efficiency reaches 99.99%.

6. The design of the super-large cooling system increases the design margin by 30%, and the axial flow fan is adopted, which has the characteristics of stable wind pressure and lower airflow sound.

7. 45°C high-temperature protection design ensures normal operation at high temperatures.
